Customize Industrial Processing EAF Dust from Wealz Kiln

Product Categories
Zhengzhou Hengyang Industrial Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Customize Industrial Processing EAF Dust from Wealz Kiln

  • 1
  • 2
  • 3

Brand Name : hengyang

Model Number : wealz KILN

Certification : ISO9001

Place of Origin : China

MOQ : 1

Price : 35000-95700USD/set

Payment Terms : T/T

Supply Ability : 30sets/month

Delivery Time : 15-20 days

Packaging Details : Negociated

Capacity : 0.9-40t/h

Power : 18.5-132kw

Color : customize

OEM : Accept

EPC : Accept

Contact Now

The Waelz Kiln is the dominant technology accounting for 80% of total crude zinc oxides production worldwide from EAF dust sources. In the Waelz process EAF steel dust is mixed with solid reducing agent and lime or silica, pelletized and then it is fed to the kiln and heated to reaction temperature to volatilize the non-ferrous metals like zinc and lead, while ferrous oxides are also reduced. The main components of the Waelz oxides are volatilized oxides of non-ferrous metals (Zn,Pb, Cd, etc.) and also halogens (mainly chlorides), alkaline metals (Na, K), and some sulphur oxide.

Nowadays, the major part of Waelz oxide is used by primary zinc smelters to produce electrolytic zinc. Because halogens content in the Waelz oxide have a detrimental effect in zinc electro-winning, the zinc smelters normally request a concentration of each CI and F not higher than 0.1%which requires a washing step. Nonetheless, the ratio of washed crude zinc oxides blended with sulphide concentrates that can be fed to the roaster is usually not higher than 10%. The direct feeding of washed Waelz oxide to the leaching is hardly applied.Customize Industrial Processing EAF Dust from Wealz Kiln

Kiln Technical Details:

Specification Model
(m)

The size of the kiln

Yield
(t/h)

Speed
(r/min)

Electrical power (kw)

Weight
(t)

Remarks

Diameter
(m)

Length
(m)

Gradient
(%)

φ1.4×33

1.4

33

3

0.9-1.3

0.39-3.96

18.5

47.5

----

φ1.6×36

1.6

36

4

1.2-1.9

0.26-2.63

22

52

----

φ1.8×45

1.8

45

4

1.9-2.4

0.16-1.62

30

78.2

----

φ1.9×39

1.9

39

4

1.65-3

0.29-2.93

30

77.59

----

φ2.0×40

2

40

3

2.5-4

0.23-2.26

37

119.1

----

φ2.2×45

2.2

45

3.5

3.4-5.4

0.21-2.44

45

128.3

----

φ2.5×40

2.5

40

3.5

9.0-10.5

0.44-2.44

55

149.61

----

φ2.5×50

2.5

50

3

6.25-7.4

0.62-1.86

55

187.37

----

φ2.5×54

2.5

54

3.5

6.9-8.5

0.48-1.45

55

196.29

----

φ2.7×42

2.7

42

3.5

10.0-11.0

0.10-1.52

55

198.5

----

φ2.8×44

2.8

44

3.5

12.5-13.5

0.437-2.18

55

201.58

Preheater kiln

φ3.0×45

3

45

3.5

12.8-14.5

0.5-2.47

75

210.94

----

φ3.0×48

3

48

3.5

25.6-29.3

0.6-3.48

100

237

φ3.0×60

3

60

3.5

12.3-14.1

0.3-2

100

310

----

φ3.2×50

3.2

50

4

40.5-42

0.6-3

125

278
